Frequency-doubled diode-pumped disk lasers

Our trusted 532 nm laser sources with up to 8W continuous-wave output power for proven applications in medicine, illumination and signaling

Jenoptik has pioneered development and commercialization of diode-pumped thin disk laser technology and has over 25 years experience in the design and fabrication of diode-pumped solid state lasers.

With more than 25.000 units installed, our cw-532 nm thin disk lasers are proven in the field for a variety of applications such as ophthalmology, dermatology, veterinary medicine, laser projection and quality control.

Operation of our 532 nm thin disk lasers relies on TEC-controlled laser diode pump sources from our in house-fab, Nd:YVO4 gain crystals and TEC-controlled internal frequency doubling LBO crystals. Compared to other solid-state laser technologies, thin disk lasers offer highest electro-optical efficiency, water-less cooling of the gain medium and high beam quality (M² ~ 5) due to suppression of thermal lensing. This enables us to serve applications in the medical field of laser-based-therapy with our proven and highly reliable JenLas® D2.x and JenLas® D2.mini series.

The miniaturized JenLas® D2.mini 2-8W with its industry-leading, lowest form-factor fits into the palm of your hand and exhibits a rugged, sealed OEM-design for easy integration into your medical laser system.

Three levels of integration are available:

  • JenLas® D2.mini 2-8W free-space
  • JenLas® D2.mini 3/8 W FC: fiber coupling into 100 µm core, NA = 0.11 (standard))
  • JenLas® MLS Green: fully integrated, i.e. including fiber-coupling, control electronics, cooling and functional safety features conforming with the IEC 60601 medical electrical equipment norm
The MLS Green presents a generic platform from which we derive customized medical lasers systems.
Video

Make use of our laser product portfolio to configure and co-develop with us the laser solution you need.
